Automatic High Speed Chocolate Foil Wrapping Machine with 180-240 ppm Packing Speed for 15-32 mm Chocolate Size Using Foil/Film Wrapper Material
High-quality New Design Full Automatic Sesame balls Wrapping Machine
Technical Specifications
| Parameter | Specification |
|---|
| Product Name | Sesame balls wrapping machine |
| Model No | SL-SBJS260 |
| Wrapping Speed | 180-240ppm |
| Chocolate Size (Diameter) | 15-32 mm |
| Total Power | 5 KW |
| Power Supply | 380V/220V 50HZ 3P |
| Air Supply | 0.6Mpa |
| Qualification Rate of Packaging | >=97% |
| Air Displacement | 0.6 m³/min |
| Wrapper Width (L*W) | 100*100mm |
| Wrapper Material | Foil/PET/Film and so on |
Machine Overview
This complete machine is a fully automatic high-speed wrapping machine, which uses automatic control to convey and pack foods, such as chocolate, sesame balls, and other foods that are not easily handled or fragile. Ferrero Rocher aluminum foil pack is available by replacing some parts.
Application Range
SL-SBJS260 series machines are dedicated to the automatic wrapping of sesame balls, also suitable for various shapes and sizes, such as Tresor Dore (Ferrero Rocher) chocolate product package. The model uses aluminum foil as a wrapping material. The unique design and technology ensure an excellent wrapping performance at all times.
Product Details
Key Advantages
- Adopt PLC & program software, easy to operate and set with auto-human touch screen and three color warning light
- Fully automatic program-controlled with servo motors, highly stable and reliable
- Flexible color sensor settings with paper feeding self-tracking and correction during packing
- Self-protection for abnormal product detection
- Online product feeding status monitoring for minimal paper consumption
- Removable truckle with adjustable height for easy mobility
- Large space switch power supply with optional electrical device brands
Company Introduction
Chengdu ShengLi Machinery Equipment Co., LTD is a professional company specializing in the design, development, production, and sales of food processing and packing machinery. We provide automatic food processing solutions and customer services for decades (Chengdu WealthRise Complete Mechanical Engineering Co., Ltd is a wholly foreign-owned enterprise founded in 2004).
Packing & Shipping
Package Standard
Wooden case package as the international trade package
Package Supply and Recovery
The supplier supplies package according to customer requirements and recovery depends on the customer
Package Size and Weight (Reference)
| Component | Gross Weight | Dimensions (L*W*H) |
|---|
| Wrapping Machine | 1600KG | 2970*1570*2250mm*1 |
| Feeding Conveyor | 400KG | 2570*1070*1450mm*1 |
| Total | 2000KG | 14m³ |
Frequently Asked Questions
What's the payment term you accept?
By T/T or L/C.
What's your delivery time?
Normal time is 60 days for a single packing machine, except for custom packing machines. The actual time will vary from different order conditions.
How do you pack your machine for shipment?
The machine is overwrapped with plastic film and then packed in fully closed standard wooden cases with a strong bottom pallet.
How to control your machine quality?
Quality is our belief. We are always focused on Professional design and quality. High precision for parts processing. Use of quality raw material. Use of international brand electrical components. Assembly as per technical standard. Performing trial running and pre-shipment inspection.
Which countries have you ever exported your machines to?
Malaysia, Belgium, Korea, Russia, Hungary, USA(California), Mexico, India, Turkey, Tajikistan, Uzbekistan, Ukraine, Vietnam, Ecuador, Algeria, California, and Ukraine.
Why choose us?
(1) Quality machine: Beautiful outer shape and rational configuration. High-quality material and renowned international brand electrical components. Advanced control system with PLC, HMI, and Servo. Simple and easy debugging and operation. Strong functionality, stable performance, and easy maintenance. High cost-effective performance.
(2) Technical service: OEM manufacturing. Free on-site technical training. Optimal customized solution. Quick response to the user's query. Highly efficient and satisfied after-sales service.
What's the language used for the operating system?
English is used as an operation control language.
What's the warranty period?
12 months after shipment.
What about after-sales service?
When necessary, we will send our technician to the customer's factory to install, debugging and operate the machines, as well as free technical training service. But, our customer shall bear the service cost for visa, round-trip ticket, meal, hotel, and a daily allowance of usd100.
